The SUB 12.17 EDGE is based on the consistent development of its famous predecessor, SUB 12.17. By making use of the latest ICEpower® technology, the subwoofer is able to perform with even more power and dynamics. While the RMS power increased to astonishing 700W, the peak power now even reaches 1045W which makes the 12.17 EDGE a real powerhouse. Furthermore, the new amplifier offers additional sound tuning options. The driver of the 12.17 EDGE has to be powerful yet very rigid and at the same time extremely lightweight to achieve the highest precision and maximum power. Therefore, a driver which originates from the famous Cinema series which is able to achieve this high set of goals is used. All these properties make the 12.17 EDGE an outstanding, powerful and very versatile subwoofer for your home cinema or music system.
XTZ – SUB 12.17 Edge – Subwoofer
SUB 12.17 EDGE – Dynamic and articulate bass performance
Description
Additional information
| Weight | 25.9 kg |
|---|---|
| Construction Type: | 12" aktiv hybrid subwoofer (Bassreflex / Sealed) |
| Color | gloss black, matte black, matte white |
| Power | 1045 W Peak / 700 W RMS, Class-D, ICEpower |
| Dimensions (H x W x D) | 395 x 510 x 400 mm (W x H x D) / 15.7 x 20.7 x 15.9" (Height incl. spikes) |
| Drivers | 1 x 300 mm (12") High-Speed Ultra-Long-Stroke driver (Polymer reinforced cotton) |
| Frequency Response | 19 – 180 Hz (+/- 3dB) |
| Connections | 2 x RCA, XLR, XLR-Passthrough |
| Settings | 3 x EQ (REF, Bassreflex / Sealed (2 ports), EQ1, EQ2) |
| CROSSOVER FREQUENCY | Bypass, Variable 40 – 160Hz |
